RS232 to 4 RS232 & 4 RS422/RS485 Convertor Distributor : LD-1044UDP

The Milestone LD-1044UDP is a multi-format serial data distributor that takes a single RS232 input and feeds it to four RS232 outputs and four RS422/RS485 outputs simultaneously. This lets one host computer, PLC or controller drive up to eight separate serial devices covering different interface standards from a single source. Each output is buffered and isolated, keeping data clean and reliable even when remote devices sit at a distance or in electrically noisy environments. It is an ideal central distribution point for control rooms, server rooms and industrial panels where RS232 and RS422/RS485 equipment must work together.

Key Features

• Dual Protocol Signal Splitting (4 RS232 + 4 RS422/RS485): Accepts a single master input and simultaneously converts/distributes it into 4 independent RS232 channels and 4 independent RS422/RS485 channels.

• Selectable 2-Wire & 4-Wire Operating Modes: Supports both 2-wire half-duplex (RS485) and 4-wire full-duplex (RS422/RS485) modes across all differential serial channels via onboard switches/jumpers.

• Optoelectronic Isolation & Surge Suppression: Features integrated galvanic/optical isolation to protect host systems, controllers, and connected slave field devices against high-voltage ground loops and power surges.

• Automatic Direction & Baud Control: Equipped with auto-baud rate sensing and hardware data flow management, eliminating the need for software-driven RTS/CTS handshaking lines.

• Front-Panel LED Diagnostics: Features clear LED status indicators for Power, Master Transmit (TX), and individual Receive (RX) lines for quick real-time connection status and signal troubleshooting.

• Industrial-Grade Metal Chassis: Encased in a rugged metal enclosure designed for continuous, reliable operation in factory automation panels, SCADA setups, and industrial control rooms.

Applications
• Feeding a single serial host to multiple RS232 and RS422/RS485 devices
• Connecting mixed-interface equipment such as displays, kiosks and controllers
• Broadcasting data to multiple instruments in laboratory and test setups
• Fanning out control signals in building automation and AV systems
• Extending serial connectivity in security and command-and-control rooms
• Distributing data in industrial automation and process control networks

Summary
The Milestone LD-1044UDP gives integrators a single clean point to distribute one RS232 signal to four RS232 and four RS422/RS485 devices at the same time. With buffered, isolated outputs and LED diagnostics, it makes mixed-interface serial networking simple, reliable and easy to maintain.
