The Raylogic DIN‑F8‑KNX is a DIN‑rail mounted, eight‑channel analog dimming module, equipped with optional KNX bus integration. It supports 0‑10 V DC or PWM dimming and can switch lighting loads up to 16 A per channel. Designed for scalable, seamless automation, it communicates via Raylogic’s proprietary RAYNET RS‑485 protocol, IP, the GO app, keypads, and integrates with KNX systems controlled via ETS configuration.
Specification Table
| Specification | Details |
|---|---|
| Form Factor | DIN‑rail mounted, dimensions: 210 mm (W) × 100 mm (H) × 80 mm (D) |
| Output Channels | 8 analog control channels (0‑10 V DC / PWM). Switching for LED/incandescent/fluorescent up to 16 A |
| Dimming Control | Direct channel intensity and programmable fade time (0–250 seconds) |
| Scene & Memory | Internal non‑volatile memory for up to 60 scenes, schedules, timers; stores last state |
| Grouping | Supports 16 groups or areas |
| Power Supply | Built‑in power supply; can power up to two Raylogic keypads |
| Networking & Control | RAYNET RS‑485; IP via built‑in Ethernet; GO app support; web‑server setup; third‑party RS‑485 control |
| KNX Integration | Optional KNX interface, configured via ETS |
| Protection | Requires external fuses/MCBs; housed in mild steel, powder‑coated enclosure |
| Manual Overrides | In‑built touch switches on the top panel for manual control |
| Voice Control Integration | Supports Alexa GO skill, Google Home GO action, IFTTT (GO service), and Siri Shortcuts |
Key Features
• Versatile Analog Dimming: Handles 0‑10 V or PWM dimming for diverse lighting types with high load capacity (16 A per channel).
• Custom Scenes & Scheduling: Save up to 60 scenes and automate lighting with schedules and timers.
• Flexible Control Options: Manage via RAYNET RS‑485, Ethernet (GO app), web server, or KNX (via ETS).
• Extensive Integration: Works with Raylogic keypads and automation ecosystem, plus third‑party control systems.
• Scalable Grouping: Organize eight channels into up to 16 distinct groups for intuitive control.
• Simplified Manual Control: Touch‑switch overrides allow on‑the‑spot adjustments.
• Smart Home Compatibility: Seamless voice control and app integration through popular voice assistants.
• Robust Build & Safety: Metal enclosure ensures durability; external fuses/MCBs for protection.
Applications
The DIN‑F8‑KNX module is ideal for:
• Residential Automation: Central control of home lighting—living areas, kitchens, bedrooms—with scenes like "Night Mode" or "Movie Time".
• Commercial Spaces: Offices, boardrooms, lobbies, where IP control, scheduling, and grouping enhance operation and energy management.
• Hospitality Settings: Hotels, restaurants, and banquet halls benefit from preset mood lighting and guest customization.
• Restoration & Retrofitting: Enables analog dimming upgrades while keeping existing wiring intact.
• KNX‑based Projects: Easily integrates into larger KNX automation systems, supporting centralized configuration via ETS.
• Hybrid Setups: Merges analog dimming with digital control systems, bridging older lighting tech with modern smart systems.
Summary
The Raylogic DIN‑F8‑KNX merges analog dimming capability with modern automation via KNX and Raylogic’s own ecosystem. With robust control options, programmability, and integration features, it’s well-suited for projects requiring fine-grained, scalable lighting management—across homes, commercial venues, and retrofits alike.
