Raylogic DIN-H81-KNX
Raylogic DIN-H81-KNX
The Raylogic DIN‑H81‑KNX is a compact DIN‑rail lighting control module featuring 8 channels of leading‑edge (phase‑cut) dimming. Each channel handles up to 300 W, making it well-suited for LED lamps with compatible drivers. Built for integration with Raylogic’s RAYNET ecosystem and smart-home solutions, it supports configuration over KNX via ETS, offers web‑based setup, and enables control through Raylogic’s apps, keypads, or voice assistants.
Specification Table
| Specification | Details |
|---|---|
| Mounting & Dimensions | DIN‑rail mount; approx. 210 × 100 × 80 mm |
| Output Channels | 8 discrete leading‑edge dimming channels |
| Max Load per Channel | 1.25 A (approx. 300 W) |
| LED Driver Compatibility | Up to 10×(5–21 W) drivers, 5×(25–50 W), or 1×(50–250 W) per channel |
| Scene & Scheduling | Built‑in non‑volatile memory for 60 scenes, timers, schedules, and last‑state retention |
| Scene Fade Time | Programmable from 0 to 250 seconds |
| Grouping | Up to 16 groups/areas supported |
| Power Supply | Internal supply; can power up to 2 Raylogic keypads |
| Synchronization | Automatic frequency tracking |
| Networking & Integration | RAYNET RS‑485 protocol; IP interface via built‑in Ethernet/Web Server; optional KNX integration via ETS |
| Protection | Thermal overload cut-off; requires external fuses/MCBs; housed in powder-coated mild steel enclosure |
| Control Methods | Raylogic GO app, Touchmate app, RAYNET keypads, push‑button interface (optional), direct touch‑channel control on module |
| Voice & Service Integration | Alexa (GO Skill), Google Home, IFTTT, Siri Shortcuts |
Key Features (Short & Sweet)
• 8 x Phase‑Cut Dimming Channels — Each channel delivers up to 300 W of dimming power.
• Scene Memory & Timing — 60 pre‑programmable scenes, with fade time control and schedule support.
• Multi-Interface Control — Works over RAYNET (RS‑485), Ethernet (built‑in web server), and optionally via KNX/ETS.
• Local & Remote Operation — Control using apps, keypads, optional push-buttons, or onboard touch interface.
• Smart Home Ready — Compatible with Alexa, Google Home, IFTTT, and Siri Shortcuts.
• Safe & Rugged Build — Thermal overload protection, housed in durable enclosures; requires external MCB/fuse.
Applications
• Multi‑Room/Dynamic Lighting — Perfect for residential or commercial spaces needing multi-channel dimming (lounges, media rooms, dining areas).
• Mood & Scene Control — Ideal for lighting scenes with smooth fades—think entertainment zones, ambiance lighting, or retail displays.
• Smart Building Integration — Seamlessly fits into KNX-based or app-controlled smart building setups.
• LED Installations — Supports a range of dimmable LED fittings—from strips to high‑wattage fixtures.
• Retrofits & Scalability — Great for upgrading lighting control in existing frameworks without replacing entire ecosystems.
Summary
The Raylogic DIN‑H81‑KNX module delivers robust performance and flexibility for multi-channel lighting control. With strong dimming capacity, scene programming, multiple control pathways (including KNX compatibility), and smart home integration, it's a powerful choice for both residential and commercial automation setups.
