The Raylogic DIN‑RE16‑KNX is a robust, DIN‑rail mounted relay interface module offering 16 independent relay channels for smart lighting and load control. Designed for seamless integration into both Raylogic and KNX automation ecosystems, it supports control via RAYNET RS‑485, Ethernet/IP, mobile apps, voice assistants, and ETS-configured KNX systems. Equipped with internal scene and schedule memory, it is ideal for scalable, automated installations across residences and commercial spaces.
Specification Table
| Specification |
Details |
| Mounting Type |
DIN‑rail |
| Relay Channels |
16 independent outputs |
| Load Capacity |
Up to 16 A per channel (assumed based on similar models) |
| Dimensions |
Likely ~210 mm (W) × 100 mm (H) × 80 mm (D) – similar to DIN‑RE8 |
| Scene Memory |
60 scenes, schedules, timers, and “last state” storage (expected same as DIN‑RE8) |
| Power Supply |
Built‑in PSU with ability to power up to 2 Raylogic keypads (expected as per other DIN modules) |
| Networking |
RAYNET RS‑485, Ethernet/IP, optional KNX via ETS, built‑in web server |
| Control Methods |
GO app, Touchmate app, Raylogic keypads, push‑button interface, top‑panel touch, voice assistants (Alexa, Google, Siri), IFTTT |
| Protection & Enclosure |
Mild‑steel, powder‑coated casing; requires external fuses and MCBs |
Note: Some specifications are extrapolated from the 8‑channel model (DIN‑RE8), as explicit data for the 16‑channel variant is not available publicly.
Key Features
• High Channel Density: Offers 16 relay channels, ideal for complex, multi-zone installations (inferred from product naming convention).
• All-in-One Automation: Includes internal memory for scenes, schedules, and last‑state retention for automation continuity.
• Built‑in Power & Control: Incorporates power for external keypads and offers flexible manual and app-based controls.
• Versatile Integration: Supports RAYNET, Ethernet/IP, and optional KNX integration — highly adaptable to various building automation standards.
• User-Friendly Setup: Embedded web server simplifies configuration; controls via apps, keypads, push buttons, or voice commands.
• Durable and Safe Design: Rugged housing with external circuit protection ensures reliability in electrical panels.
Applications
• Large Homes & Villas: Centralized control of extensive lighting zones, motorized curtains, or multi-room lighting automation.
• Hospitality Spaces: Efficient management of guest rooms, banquet halls, and corridors via programmable scenes and schedules.
• Commercial Buildings: Ideal for controlling lighting and other loads across offices, meeting rooms, and lobbies.
• KNX Integration Hubs: Bridges Raylogic’s ecosystem with established KNX setups, allowing hybrid automation networks.
• Retrofit Smart Upgrades: Enables expansion of smart automation in existing installations with minimal rewiring.
Summary
While the DIN‑RE16‑KNX isn’t detailed explicitly in available sources, its features and structure can be reliably inferred based on Raylogic’s modular DIN product line. It presents a high-channel, automation-ready relay module tailored for smart building control, combining powerful integration capabilities with user-friendly control mechanisms.
