The Ajax ReX 2 Jeweller is a next-gen wireless range extender designed to boost both alarm and visual-verification coverage for Ajax security systems. Supporting both Jeweller (alarms/events) and Wings (photo transmission) protocols, it enables deployment of MotionCam detectors well beyond the hub’s native reach, including through concrete and metal structures. Its dual communication channels—radio and Ethernet—ensure robust connection reliability.
Key Features
• Unified dual-channel communication:
Transmits events and alarms over Jeweller and delivers photos over Wings or via Ethernet—switches automatically to Ethernet if radio is lost, ensuring stable, multimodal communication.
• Visual alarm verification support:
Fully compatible with MotionCam and MotionCam Outdoor detectors, delivering first snapshots in about 10 seconds via Ethernet and around 18 seconds via Wings over radio.
• Extended coverage range:
Supports communication with the hub and devices up to 1,700 m in open space. With up to 5 ReX 2 units, total facility coverage can reach ~35 km².
• Rapid, low-latency alarms:
Alarm signals delivered in approximately 0.3 seconds.
• Independent decision-making:
Powered by OS Malevich, ReX 2 acts as a secondary control panel—able to manage devices, trigger local sirens, and continue protection autonomously if hub connection fails.
• Battery backup:
Built-in Li‑ion 2 Ah battery provides up to 38 hours of backup operation (up to 12 hours when using Ethernet), enabling protection during power loss.
• Robust anti-sabotage protection:
Includes tamper detection, jamming alerts, anti-spoofing authentication, frequency hopping, and AES encryption with dynamic keys.
• Over-the-air firmware updates:
Continuously adds new functionality via secure OTA updates.
• Easy installation:
Setup via scanning a QR code in the Ajax app, followed by naming and placement testing. Mounted using SmartBracket without opening the enclosure. Configuration and updates handled remotely via mobile or desktop apps.
• Certified compatibility:
Works only with Hub 2 and Hub 2 Plus (OS Malevich version 2.12 or newer); cannot pair with other range extenders. UL/ULC certification applies to select hub models.
Applications
• Large residential estates and multi‑floor homes:
Extends radio signals to remote outbuildings, garages, basements, and across large properties. Photo verification helps assess motion alerts remotely.
• Commercial buildings and offices:
Ideal for expansive layouts, multiple floors, metal or concrete construction—with reliable alarm/photo transmission via Ethernet where radio may falter.
• Industrial facilities and warehouses:
Supports large, segmented facilities like factories or hangars, even with metal structures or underground areas, using Ethernet-based connection when needed.
• Multi‑site or distributed properties:
Enables deployment of up to five ReX 2 units per system to cover sprawling grounds or several separate buildings under a unified security network.
Summary :
The Ajax ReX 2 (8IN) is more than a signal repeater—it's a smart, secure, autonomous node in your Ajax system. With enhanced range, alarm-photo verification via Wings/Ethernet, resilient dual-channel connectivity, and deep tamper protections, it's ideal for large-scale residential, commercial, or industrial sites requiring both extensive coverage and visual intrusion verification.
